QSC

• Very low installation depth: 259 mm
• Weight: Only 6 kg
• Power: 2x 1200 W at 4 ohms
• Hi-peak power up to 4500 W
• Class-D output circuitry
• Large, backlit 256p x 128p LC display
• 2 Rotary encoders and 3 buttons for quick access
• High-pass filter, 4th-order Linkwitz-Riley, adjustable frequency of 20 Hz up to 4 kHz
• Low pass filter, 4th-order Linkwitz-Riley, adjustable frequency of 60 Hz up to 4 kHz
• 4-Band parametric EQ with frequencies
• Variable gain and bandwidth
• Peak limiter: Protects the loudspeaker via the input of all individual power- and impedance data
• Delay: Max. 50 ms
• Digital gain: +10 dB / -100 dB
• 20 Presets for the most popular speaker configurations, adjustable
• Status LEDs: 2x Green: Signal / 2x Red: A/D Clip / 1x Blue: Indicates AC on
• Inputs: 2x XLR and 2x 6.35 mm stereo jack
• Outputs: 2x NL4, lockable (NL2 compatible) and 2x binding posts
• Mono- or bi-amping connector
• Protected circuit design and thermal protection
• Power supply secured in case of instable power supply
• Removable power cable (C13/safety plug)
• Dimensions (W x H x D): 483 x 89 x 259 mm
• Design: 19", 2U

Bundle offer comprising

• 2-Way Full-Range Active Speaker
• 1,000 watt Class D amplifier output power
• 2,000 Watt Hi-Peak Amplifier Output Power
• Assembly: 12" Woofers and 1.75" voice coil
• Dispersion: (-6 dB): 75° axis-symmetrical
• Frequency range (-10 dB): 50 - 20000 Hz
• Max. Sound pressure level (1m): 131 dB
• Built-in two-channel mixer
• Channel A Input: XLR / jack combi jack, Mic / Line input switchable: Mic 24dB / 36dB with MIC LED or line: 0dB / 12dB, gain control, signal LED
• Channel A Output: XLR
• Channel B Input: XLR / jack combo socket and 2 x RCA jacks L / R, line input, gain control, signal LED
• Channel B Output: XLR
• Channel A + B Output: XLR
• Remote volume control via Euro-jack of several loudspeakers for installation application
• DSP corrects non-linear distortions
• EQ modes "DEEP" for rich bass without sub and "vocal" for precise voice reproduction
• "GuardRail" protects power amplifier without switching off
• Slanted monitor angle: can also be used as floor monitor: can also be used as floor monitor
• 35 mm Pole sockets with Tilt-Direct: 0° / -7.5°, e.g. Art.323921
• Speaker grille made of powder coated steel
• Housing made of 15 mm birch multiplex with aluminum handles
• 6 x M10 Mounting points for flying suspension
• Slip resistant feet
• Locking power cable, length: 3 meters (C13 / protective contact)
• Low power consumption: up to 8 KW series loudspeakers can be operated on a 10A / 230V standard line
• Auto standby mode
• Dimensions (H x W x D): 660 x 381 x 391 mm
• Weight: 22.2 kg
• Six years manufacturer's warranty upon product registration
• Suitable protective cover KW122 Outdoor Cover available: Art.260336 (not included)

• Cover
• For KW 122
• With cable compartment

• 3600 W Class D amplifier module
• direct radiating 18" long excursion direct radiating driver
• Frequency response: 35 - 111 Hz
• Max. SPL (sound pressure level): 136 dB
• Nominal coverage angle: Omnidirectional (360°) or cardioid - Cardioid setup requires at least 2x KS118 units
• DEEP mode
• Multi-functional display
• Adjustable crossover and delay
• Gain control
• Signal LED
• Limiter LED
• Power LED
• High-performance DSP
• 2 XLR/Jack combo line inputs for channels A and B
• 2 XLR/M outputs for channels A and B
• Vertical and horizontal deployment possible
• M20 threaded pole receiver
• 18 mm Birch plywood housing with impact-resistant lacquer finish
• 4 Heavy-duty casters
• LOCK power cable (length: 3 m)
• Dimensions including casters (H x W x D): 640 x 520 x 785 mm
• Weight: 47 kg
• Colour: Black
• Suitable cover available under Article Nr 475505 (not included)

• Suitable for QSC CP8
• Colour: Black

• Suitable for the QSC K12 and K12.2
• Made from nylon fabric
• Allows access to the connection panel
• Colour: Black

Note: Not suitable for permanent outdoor use.

• 2,000 Watt Class D amplifier module
• Equipped with: 8" Woofer and 1.4" titanium compression driver
• Dispersion pattern: 105° axisymmetric
• Multi-function display (45 mm x 25.4 mm) / 2 selection buttons
• Presets / EQ presets: Dance / Floor monitor / Vocal / Acoustic guitar / Bass guitar / Hand microphone / Headset microphone etc.
• Scenes can be saved and recalled: User EQ / Delay / Crossover and input selection
• High-performance DSP, corrects non-linear distortions
• Frequency range (-10 dB): 55 - 20000 Hz
• Maximum SPL (@ 1m): 128 dB
• Channel A Input: 1 x XLR/jack combo socket
• Mic / Line input (switchable)
• Gain control
• Signal LED Channel A Output: 1 x XLR
• Channel B input: 1 x XLR/jack combo socket and Hi-Z/Line input (switchable)
• Gain control
• Signal LED channel B output: 1 x XLR
• Channel C Input: 1 x 3.5 mm stereo jack
• Gain control
• Signal LED
• Three-Channel Mixer: Mix-Out Output (Post Gain): 1 x XLR
• Slanted monitor angle: 55°, can also be used as floor monitor
• 35 mm stand flange mount with 0° or -7.5° orientation
• Speaker grille made of powder coated steel
• Lightweight housing made of high-strength ABS / ergonomic handles
• 2 M10 Rigging points with integrated PullBack eyelet
• V-LOCK power cable with lock for safe operation (C13 / earthed connector)
• Low power consumption: Several K.2 series loudspeakers can be operated with a 10 A / 230 V standard cable
• Dimensions (H x W x D): 449 x 280 x 269 mm
• Weight: 12.2 kg
• 6 Years manufacturer's warranty upon product registration
• Suitable bags: Article Nr: 243080 or Article Nr: 431993 (both not included)
• Suitable bracket for mounting on the wall or ceiling : Article Nr: 414695 (not included)
• Suitable cover: Article Nr: 304010 (not included)

• Very low installation depth: 259 mm
• Power: 2x 600 W into 4 Ohm, 2x 400 W into 8 Ohm
• Hi-Peak power: up to 1,600 W
• Class-D power amplifier circuit
• Large, illuminated 256p x 128p LC display
• 2 Rotary input knobs and 3 buttons for quick access
• High-pass filter, 4th order Linkwitz-Riley, adjustable frequencies 20 Hz to 4 kHz
• Low-pass filter, 4th order Linkwitz-Riley, adjustable frequencies 60 Hz to 4 kHz
• 4-Band parametric EQ with frequencies
• Gain and bandwidth variable
• Peak Limiter: protects speakers by entering individual power and impedance data
• Delay: maximum 50 ms
• Digital gain: +10 dB / -100 dB
• 20 Presets for the most frequently used loudspeaker configurations, adjustable
• Status LEDs: 2x green: signal/2x red: in-amp clip/1 xblue: mains power
• Inputs: 2x XLR and 2x 6.35 mm stereo jack
• Outputs: 2x NL4, lockable (NL2 compatible) and 2x screw terminals
• Mono or bi-amping connection
• Protection circuits and thermal fuses
• Power supply fused in case of unstable power supply
• Detachable mains cable (C13/grounded plug)
• Dimensions (W x H x D): 483 x 89 x 259 mm
• Construction: 19" / 2 U
• Weight: 5.1 kg

• Power: 2x 425 W / 4 Ohm, 2x 350 W / 8 Ohm
• Inputs channel 1 and 2: 2x XLR balanced, 2x RCA and 2x 6.3 mm stereo jacks
• Outputs: Speaker Twist combo jacks to 6.35 mm jack, 2 x screw terminals
• 2 Stepped gain controls for precise adjustment
• Frequency range: 20 - 20,000 Hz
• Signal / noise ratio: 100 dB
• Integrated switchable crossover
• Guard rail technology
• Protects against overheating and overloading without disconnecting
• Protective circuits and thermal fuses
• Detachable power cable
• Very low installation depth and low weight
• Dimensions (W x H x D) 483 x 89 x 257 mm
• Format: 19" / 2 U
• Weight: 12.1 kg

• Format: 19" / 2 U
• 2x 300 W / 4 Ohms
• 2x 200 W / 8 Ohms
• 2x 430 W / 2 Ohms
• 1 x 830 W / 2 Ohm stereo or 4 ohm bridged applications
• Balanced TRS, XLR, and barrier strip inputs
• Mono parallel mode
• Speaker Twist and binding post outputs
• Adjustable-/ switchable HP filter
• Switchable limiter
• GND Lift
• Amplifier and circuit protection
• Quiet fan
• Weight: 15.9 kg
• Housing depth: 36 cm
• 3 Year warranty

• Rated power: 800 watts continuous power / 3,200 watts peak power
• Nominal impedance: 4 ohms
• Frequency range (-10 dB): 32 - 230 Hz
• Max. Sound pressure (1 m): 133 dB
• Inputs: 2x speaker twist (1x through) and screw terminals
• M20 threaded pole mount
• Multiplex housing with shockproof black textured paint
• Mounting points for swivel castor wheels (castors not included)
• 4 Stable ergonomic handles made of metal
• Dimensions (H x W x D): 616 x 590 x 605 mm
• Weight: 48 kg
• Colour: Black
• Includes 35 mm speaker pole with M20 thread (length: 61 cm)

Suitable accessories (not included):

• Cover: Art.451747 (not included)
• Subwoofer Caster Kit wheel set: Art.451752 (not included)

• 2000 W Class D amplifier module
• Speaker setup: 12" Woofer, 1.4" Titanium diaphragm compression driver
• Nominal coverage angle: 75° Axisymmetric
• 45 x 25.4 mm Multifunction display / 2 Selection keys
• Presets/EQ presets: Live/Dance/Monitor/Vocals/Acoustic Guitar/Bass Guitar/Hand Microphone/Headset Microphone, etc.
• Scenes can be stored and recalled: User EQ/Delay/Crossover/Input Selection
• High-performance DSP - Corrects non-linear distortion
• Frequency range (-10 dB): 45 - 20,000 Hz
• Max. rated SPL @ 1 m (sound pressure level): 132 dB
• Channel A input: 1 x XLR/Jack combo socket
• Mic/Line input (switchable)
• Gain control
• Channel A signal LED output: 1 x XLR
• Channel B input: 1 x XLR/Jack combo socket and Hi-Z/line input (switchable)
• Gain control
• Signal LED channel B output: 1 x XLR
• Channel C input: 1 x 3.5 mm Stereo jack
• Gain control
• Signal LED
• 3-Channal mixer: Mix output (post gain):1 x XLR
• Monitor angle: 55°; Can also be used as a floor monitor
• 35 mm Speaker stand mount with 0° (standard) or -7.5° (down tilt)
• Speaker grille made of powder-coated steel
• Lightweight housing made from impact resistant ABS/ergonomically designed handles
• Attachment points: 2 M10 threaded inserts with integrated Pull-Back eyelets
• V-LOCK locking power cord for safe operation (C13/Schuko)
• Low current consumption - Several K.2 series speakers can be operated from one 10A/230V standard line
• Dimensions (H x W x D): 602 x 356 x 350 mm
• Weight: 17.4 kg
• Suitable bag available under Article Nr 243077 (not included)
• Suitable brackets for wall or ceiling mounting available under Article Nr 414699 (not included)
• Suitable cover available under Article Nr 431994 (not included)

• Suitable for QSC E118sw speakers
• Made of robust nylon / Cordura
• Protective padding
• Colour: Black with white QSC logo

• Speaker setup: 8” Woofer, 1.4” Compression driver
• Power: 500 W RMS / 1000 W peak
• Class D amplifier module without fan
• Dispersion pattern: 90° Axissymmetric
• Monitor angle: 55°
• 6 EQ presets
• High-performance DSP - Corrects non-linear distortion
• Frequency range (-10 dB): 53 - 20,000 Hz
• Max. level (@1 m): 124 dB
• Limiter LED/Protected circuit design
• Channel A input 1x XLR/Jack combo socket, Line input, Gain control (A+C input)
• Channel B input 1x XLR/Jack combo socket, Mic/Line input, Gain control
• Mic boost Switch: +25 dB for channel B
• Channel C input: 1x 3.5 mm Stereo jack (gain/signal LED via channel A)
• 3-Channel mixer: Mix output (post gain): 1x XLR
• 35 mm Stand flange mount
• Speaker grille made of powder-coated steel
• Scratch-resistant plastic housing with ergonomic handle design
• Dimensions (H x W x D): 411 x 273 x 256 mm
• Weight: 9.5 kg

Suitable accessories (not included):

• CP8 Bag available under Article Nr: 449712
• CP8 Outdoor protective cover available under Article Nr 449716
• CP8 U-Style yoke bracket for vertical and horizontal installations available under Article Nr # 449714#

Note: Register your speaker with QSC to extend its warranty to 6 years.

• Power: 2 x 700 W @ 4 Ohm
• Inputs: XLR balanced, 2x RCA and 6.3 mm stereo jack
• Outputs: Speaker Twist combo jacks to 6.35 mm jack, 2 x binding posts
• 2 Gain controls
• Frequency range: 20 - 20,000 Hz
• Signal / noise ratio: 100 dB
• Switchable crossover
• GuardRail
• Detachable power cable
• Dimensions (W x H x D) 483 x 89 x 257 mm
• Format: 19" / 2 U
• Weight: 12.6 kg

Bundle offer comprising

• 2-Way Full-Range Active Speaker
• 2,000 Watt Class D amplifier module
• Equipped with: 8" Woofer and 1.4" titanium compression driver
• Dispersion pattern: 105° axisymmetric
• Multi-function display (45 mm x 25.4 mm) / 2 selection buttons
• Presets / EQ presets: Dance / Floor monitor / Vocal / Acoustic guitar / Bass guitar / Hand microphone / Headset microphone etc.
• Scenes can be saved and recalled: User EQ / Delay / Crossover and input selection
• High-performance DSP, corrects non-linear distortions
• Frequency range (-10 dB): 55 - 20000 Hz
• Maximum SPL (@ 1m): 128 dB
• Channel A Input: 1 x XLR/jack combo socket
• Mic / Line input (switchable)
• Gain control
• Signal LED Channel A Output: 1 x XLR
• Channel B input: 1 x XLR/jack combo socket and Hi-Z/Line input (switchable)
• Gain control
• Signal LED channel B output: 1 x XLR
• Channel C Input: 1 x 3.5 mm stereo jack
• Gain control
• Signal LED
• Three-Channel Mixer: Mix-Out Output (Post Gain): 1 x XLR
• Slanted monitor angle: 55°, can also be used as floor monitor
• 35 mm stand flange mount with 0° or -7.5° orientation
• Speaker grille made of powder coated steel
• Lightweight housing made of high-strength ABS / ergonomic handles
• 2 M10 Rigging points with integrated PullBack eyelet
• V-LOCK power cable with lock for safe operation (C13 / earthed connector)
• Low power consumption: Several K.2 series loudspeakers can be operated with a 10 A / 230 V standard cable
• Dimensions (H x W x D): 449 x 280 x 269 mm
• Weight: 12.2 kg
• 6 Years manufacturer's warranty upon product registration
• Suitable bags: Article Nr: 243080 or Article Nr: 431993 (both not included)
• Suitable bracket for mounting on the wall or ceiling : Article Nr: 414695 (not included)
• Suitable cover: Article Nr: 304010 (not included)

• Transport bag
• Suitable for QSC K 8 and K 8.2
• Colour: Black

• Suitable for QSC CP8
• With access to the connector panel
• Made of nylon fabric
• For temporary outdoor use in adverse weather conditions
• Colour: Black

Note: Not suitable for permanent outdoor installation or prolonged poor weather.

• Line Array System
• Power: 500 W x 500 W amplifier
• Lightweight ABS housing
• Solo rigging system (without tools)
• Ar-Q frequency optimisation adjusts the system to the appropriate number of speakers, up to five elements (KLA12) and two basses (KLA181) on one frame
• Coverage pattern: 90° x 18°
• Equipped with: 1.75" Voice coil
• Power Twist input and output
• Pole mount
• Dimensions: 422 x 594 x 422 mm
• Weight: 25 Kg
• Suitable array frame: Art.268642 (not included in delivery)

• Suitable for the QSC K10 and K10.2
• Colour: Black
