Palmer

• 2 XLR inputs
• 1 XLR output
• Large foot switch for switching
• Channel A 0 / -15 dB switchable
• Channel B 0 / -15 dB and 0 / -6 dB switchable
• Gnd / Lift switched to input B
• Rugged metal casing
• Operation with 9 V battery
• Dimensions: 100 x 60 x 120 mm

• A mixer in its smallest possible format
• Inputs are designed specifically for electric guitars in level and impedance
• But of course they work just as well with other instruments and devices that supply line levels
• Makes it possible to input two sources and to actively mix them together on a common amplifier input
• Inputs: 2 x unbalanced 6.3 mm jack
• Input impedance: 1 M Ohm
• Max. Input Level: 1.55 V (+6 dBu)
• Output: 1x unbalanced 6.3 mm jack
• Output impedance: 10 k Ohm
• Amplification: max. X "2" (6 dB)
• Power supply via 9V battery (417473) or external 9V power supply (409939) (both optional)

• Robust metal housing
• Real wood edges
• 2x Jack/XLR combo input
• 2x RCA connector and 1x 3.5 mm Stereo jack input
• 2x XLR male output
• 1x Mono sum XLR male output
• Switchable mute
• Switchable mono-summing
• Switchable PFL
• Input selector
• Output selector
• Adjustable headphone output
• Adjustable AUX volume
• Dimensions: 218 x 77 x 100 mm
• Weight: 1140 g

• Direct injection
• 2-Channel
• PAD switch (0dB/-30dB)
• Jack as an input connector
• Balanced XLR output
• Input impedance: 68 Ohm
• Output impedance: 600 Ohms
• Transfer ratio: 10: 1
• Maximum output level: +6 dBu
• 5 year warranty

PALMER Y-Box, splitbox for guitar signals. "When I am connecting the inputs of my two amplifiers, there is a strong hum." A frequent query in the technical section of relevant specialist magazines. The solution to this problem is the Palmer Y-Box. An FET input circuit converts the high-impedance guitar signal and, at the same time, forms the driver circuit for a transformer that directs the signal to the output ground-free. The hum loop is avoided. Operation with 9 V battery recommended.

The box can also be used as cable driver for large cable length. In addition, it is possible for the output AMP2 to phase-shift the signal. This is often necessary when two (pre)amplifiers are connected in parallel.

• Clinking input with 1 Mohm input impedance
• Output AMP1 as parallel circuit
• Output AMP2 is electronically converted with a subsequent transformer stage
• Operation with 9V battery recommended
• 5 years manufacturing guarantee

• Real wood edges
• 2x Jack/XLR combo input
• 1x 3.5 mm Stereo jack input
• 2x XLR male output
• 1x 3.5 mm stereo jack out
• Switchable mute
• Switchable mono-summing
• Dimensions: 164 x 62 x 85 mm
• Weight: 750 g
• Colour: White

• Press splitter 10 channel stereo / 20 channel mono
• 2 Channels
• Input level: +20 dB
• 2 XLR inputs
• Outputs: 6.3 mm jack, RCA, XLR, controls like attenuator
• Ground lift
• Input gain
• Mic / line switch
• Phones level, etc.
• Powder coated steel
• Internal shielded power supply
• Dimensions (W x D x H): 480 x 200 x 135 mm
• Weight: 9.09 kg

• Speaker configuration: 1 x Celestion G12M-65 Greenback
• Power rating: 25 W
• Impedance: 8 Ohm mono, 16 Ohm stereo
• Cabinet material: Pressboard
• Open cabinet construction
• Front loaded
• Front covering: Fabric
• Input and output: 2 x 6.3 mm jack
• Strap handle on top
• Dimensions: (W x H x D): 580 x 450 x 290 mm
• Weight: 15.5 kg
• Colour: Black
• Incl. screws

• Nominal impedance 600 ohms
• Max. input +20 dB
• 19" / 1U
• On the front of each channel: 1 Input + 1 thru (for phantom power transmission), 2x isolated outputs
• 5 Year warranty

• Especially for electric guitar
• Output Power: 2 x 200 W @ 4 Ohm, 2x 100W bridged @ 8 Ohm: 1x 400W @ 8 Ohm
• Class D dynamic circuit
• Frequency range: 20 - 20,000 Hz
• Protection: soft start, short-circuit, DC, overheating, overvoltage
• Controls: on/ off, volume, high, low, mode (bridge/ parallel/ stereo), ground lift, limiter sensitivity
• Line input: 2x XLR and 2x 6.3 mm jack
• Speaker output: 2x speaker twist and 3x 6.3 mm jack
• Dimensions (W x H x D): 482 x 44 x 244 mm

• Robust, metal housing
• Real wood edges
• 2 x jack/XLR combo input
• 1 x 3.5 mm Stereo-jack input
• 2 x XLR male output
• 1 x 3.5 mm stereo jack out
• Switchable mute
• Switchable mono-summing
• Dimensions: 164 x 62 x 85 mm
• Weight: 750 g

• Size: 19"/1U, 90 mm deep
• 4 Channels
• XLR output is also available as a parallel port on the back
• The active circuitry allows for a high input impedance of 1 Mohm and greater sensitivity of the input signal (typical difference between in and out: -4 dB)
• Max. output voltage is +10 dBu with phantom power
• Transformer balanced output
• Via a special "floating ground" circuit the ground lift switch functions even with phantom power
• Mains adapter is firmly connected to the device
• 5 Year manufacturer's warranty

• 2 Inputs
• 2 Outputs
• Boxes can be connected in series or parallel

Palmer tauber; passive 1 channel microphone summing unit; road-ready housing made of aluminum and steel; for two dynamic microphones or two condenser mics; permeable to phantom power; reliable problem solver for sound reinforcement systems with too few mixer channels; extremely fail-safe; for connecting two microphones to one microphone; connections: input: 2x balanced XLR, output: 1x balanced XLR; no power supply needed; input impedance (1 kHz): 644 ohms; output impedance (1 kHz): 400 ohms; dimensions (WxHxD): 50 x 140 x 68 mm; weight: 0.36 kg; included in delivery: 1x Palmer tauber, 1x label (tour label), 1x rubber feet; engineered in Germany

Palmer PCAB112BXCRM 1x12" Creamback Cab; Speaker Cabinet for Electric Guitar; Equipped With: Celestion G12M-65 Creambackspeaker/s; Cabinet Construction: Open Back65Watts; Impedance: 8 Ohms; Connectors: In & Out (2 x 1/4" Jack); Housing Material: Pressboard; Baffle Material: MDF; Front Grille: Cloth; Front loaded; Top Strap Handle; Includes: Screws; Dimensions (W x H x D): 580 x 450 x 290 mm; (22,8" x 17,7" x 11,4"); Weight: 15,6 kg (34,4 lbs); Colour: Black
