MXL

• Condenser boundary microphone with 3 capsules
• 180° Pick-up range
• Frequency response: 40 - 16000 Hz
• Sampling rate: 44.1 kHz - 48 kHz
• A/D converter: 16-bit Delta Sigma with THD+N - 0.01%
• USB compatibility: USB 1.1 and 2.0
• Plug & Play without drivers
• Compatible with Windows and Mac
• Powered via USB by computer
• USB compatibility: USB 1.1 and 2.0
• Can be used for all streaming and conference systems such as Zoom, OBS, Skype, vMix, Wirecast, Streamlabs, YouTube, Facebook Live, etc.
• Headphone output: 3.5 mm jack
• Material: Metal and plastic
• Dimensions (W x H x D): 78 x 25 x 109 mm
• Weight: 190 g
• Colour: Black
• Includes 2m connection cable USB mini-B (for microphone) to USB A (for PC) and microfibre cleaning cloth

Note on installation: The supplied cable is 2 m long. If the computer is further away from the microphone, it is possible to extend the distance using an extender. To ensure optimum sound quality, the distance should not exceed 5 m.

• Cardioid polar pattern
• Frequency range: 20 Hz-18 kHz
• Sensitivity: 22mV / Pa
• Impedance: 200 Ohm
• S / N ratio: 72 dB (Ref. 1 Pa A-weighted)
• Equivalent Noise Level: 22 dB (A weighted IEC 268-4)
• Max SPL for 0.5% THD: 140 dB
• Dimensions: 50 mm x 190 mm
• Incl. Power supply, Mogami connector cables, suspension, windscreen and transport case

• Cardioid characteristic
• Frequency range: 30 - 20.000 Hz
• Impedance: 200 Ohm
• S/N Ratio: 74 dB (Ref. 1Pa A-weighted)
• Equivalent Noise Level: 20dB (A weighted IEC 268-4)
• Max SPL for 0.5% THD: 130 dB
• 48 V phantom power (+- 4 V) required
• Dimensions (Ø x H): 47 x 184 mm
• Incl. microphone clamp and storage bag

• For microphone diameter approx. 47 - 49 mm
• For MXL-1006, MXL-2001, MXL-2006, MXL-V67G, MXL-V69M, MXL-9000
• Colour: Black

• With 2 capsules
• Directional characteristic: Cardioid
• Frequency range: 30 - 20,000 Hz
• Peak SPL: 130 dB (at 0.5% THD) and 140 dB at 10 dB PAD respectively
• Capsule diameter: 25 mm/gold vapour-plated
• Impedance: 200 Ohm
• Required supply voltage: 48 Volt phantom power
• 2 Selectable sound characteristics: "Brt" for the open and bright sound of the microphones from the 60s or "Wm" for a warm and round tone
• Status LED for active sound selection
• Switch for level adjustment and bass reduction
• Includes wooden case and holder for microphone stand

• For MXL large diaphragm microphones

MXL V87; large-diaphragm FET condenser microphone; ideal for acoustic guitars, pianos, voice and vocal recording; 32mm capsule; frequency response: 20Hz - 20kHz; polar pattern: cardioid; impedance: 200Ohm; signal-to-noise ratio: 85.5dB (A-weighted); max. SPL at 0.5% THD: 136dB; power requirements: 48V phantom power; nickel-plated metal housing; included in delivery: pop filter (PF-005-SS), shock mount (USM -002) and hard mount (V6-H); dimensions (L x D): 190 x 47mm; weight: approx. 500g

• Consisting of MXL 990 large diaphragm condenser microphone and MXL 991 small diaphragm condenser microphone

MXL 990 features:

• Frequency range: 30 Hz - 20 kHz
• Sound pressure level: 130 dB max. SPL
• Cardioid
• Requires 48V phantom power
• incl. microphone mount and transport case

MXL 991 Features:

• Frequency range: 30Hz - 18kHz
• Sound pressure level: 137 dB max. SPL
• Cardioid
• Requires 48V phantom power

• Directional characteristic: Cardioid
• Frequency range: 30 Hz - 20 kHz
• -20 dB Pad switch
• Low cut
• Output Impedance: 150 Ohm
• S / N Ratio: 77 dB
• Peak SPL: 137 dB
• Requires 48 V Phantom power
• Dimensions: 110 x 23 mm
• Weight: 113 g

• Directivity: Figure 8
• Ribbon element: length 47 mm, thickness 1.8 μm aluminium
• Transmission range: 20 - 18,000 Hz
• Maximum sound pressure level: 135 dB
• Sensitivity: 1.7 mV / Pa
• Output Impedance: 270 Ohm
• Final impedance:> 1500 Ohm
• Connection: XLR 3-pol
• Dimensions: 65 x 180 mm
• Weight: 860 g
• Colour: Chrome / Gold
• Scope of delivery: R77 microphone, fork holder, recording guide, microfibre cleaning cloth and case

• Colour: Nickel-plated
• Diameter approx. 60 - 62 mm
• For MXL-990

• Black
• Diameter approx. 44 - 46 mm
• Suitable for MXL-2003

• Universal shock mount for MXL microphones

• Directional characteristic: cardioid
• Frequency range: 30 Hz - 20 kHz
• Max. SPL (sound pressure level): 130 dB
• Requires 48 V phantom power
• Dimensions: 60 x 130 mm
• Weight: 544
• Incl. shock mount and microphone clamp with 5/8" thread and carrying case (3/8" adapter available under Article Nr 383050 (not included, must be ordered separately))

• Polar pattern: Figure of eight
• 1.8 Micron aluminium band
• Frequency range: 20 Hz - 17 kHz
• Sensitivity: -56 dB (0 dB = 1V/Pa)
• 250 Ohm Impedance
• Peak SPL: ≷ 130 dB @ 1 kHz
• Dimensions: 47 x 171 mm
• Weight: 400 g
• Shock mount and case included

• Cardioid polar pattern
• With switchable 10 dB attenuator and impact sound filter
• Frequency range: 30 Hz-20 kHz
• Sensitivity: 15mV / Pa
• Impedance: 150 Ohm
• S/N ratio: 74 dB (Ref. 1 Pa A-weighted)
• Equivalent Noise Level: 20 dB (A weighted IEC 268-4)
• Max SPL for 0.5% THD: 137 dB
• High Pass Filter 6dB / octave, 150Hz
• Phantom Power 48V ± 4V required
• Size: 60 mm × 154 mm
• Including microphone suspension and transport case

• For conferences and web applications
• 12 Built-in condenser microphone capsules for 360° recording
• Compatible with Zoom web conference software
• Plug & Play - no driver installation required
• Recording radius: > 7 m
• Multiple AC-360-Z V2 can be cascaded
• Includes 4 USB-C cables, 5 V power supply and stands

Sharing characteristics of European and Japanese imports at a fraction of the price, a transformer-less design provides a solid bottom and an extremely open top end sound. The 603 S is equipped with Mogami wiring for high fidelity. It is well suited for almost any instrument and is extremely robust in use. Includes 2 MXL 603-S, 2 shock mounts and a case. A real quality tip!

• 2 Pieces MXL 603 S condenser directional microphones
• 2 Original Elastic brackets (shock mounts)
• Aluminium case
• Extremely robust design
• 20 mm Gold-plated 3 micron thin large diaphragm
• Enables exceptionally transparent recordings
• Ideal stereo pair because of hand picked individual microphones
• Frequency range: 30 Hz - 20 kHz
• Characteristics: Cardioid
• Sensitivity: 15 mV/Pa
• Impedance: 200 Ohm
• Signal / noise ratio: 77 dB (Ref. 1 Pa A-weighted)
• Noise level: 17 dB (A weighted IEC 268-4)
• Maximum sound pressure: 137 dB 0.5% THD
• Power supply: Phantom power 48V ± 4V
• Power consumption: approx. 3 mA
• Dimensions: 22 mm diameter
• Weight per microphone: 128 g
• Incl. shock mount, windscreen, case

• Black
• Diameter approx. 60 - 62 mm
• For MXL-770

• Suitable for MXL-603S
• Diameter: approx. 19 - 23 mm
• Colour: Black
